NH2004GN003WS

Character LCD 2.4″ 20×4, COG, B/L white, STN blue neg, I2C, NEG, 6H, Standard Temp., No touch

SKU: NH2004GN003WS Category: MONO LCD DISPLAY

Additional information

Technology	Mono LCD
Size	2.4"
Resolution	20×04
Shape	Rectangular
Constructive Structure	COG
Color / Polarizer	B/L white, STN blue neg
Interface	I2C
V(LCD) Onboard	NEG
View Angle	6H
Operating Temperature (°C)	-20°C + 70°C
Display Connection	Pin Strip
Touch Panel	None
Frame	No

Description

Downloads

NH2004GN003WS Specs

1 file(s) 673 KB

Download

Customization

There are a lot of different options of semi-customization:

– Resolution
– Touch panel and optical films
– Frame
– Connectors

For more information about the technology please contact technical@nextvisiondisplay.com
